MSI 2TB M470 PCIe 4.0 NVMe M.2 SSD

MSI 2TB M470 PCIe 4.0 NVMe M.2 SSD, 5000/4400 MB/s Read/Write, PCI-E NVMe 1.3, 3300 TBW, 5 Year Warranty

SPATIUM M470 PCIe 4.0 NVMe M.2
PCIe Gen4x4 interface and complies with the NVMe 1.3 standard
Sequential Read speeds up to 5000MB/s and Write speeds up to 4400MB/s
Up to 3300 TBW
Built-in data security and error-correction capabilities
1TB to 2TB capacities in M.2 2280 form factor
Suitable for both desktop and notebook
5-Year Warranty

MODEL NAME SPATIUM M470 PCIe 4.0 NVMe M.2
CAPACITY 2TB
CONTROLLER PHISON E16
FLASH MEMORY 3D NAND
DRAM CACHE 2GB DDR4
FORM FACTOR M.2 2280
INTERFACE PCIe Gen4x4, NVMe 1.3
COMPATIBILITY PCIe Gen4 / Gen3 / Gen2 / Gen1
DIMENSIONS 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
SEQUENTIAL READ UP TO (MB/S) 5000
SEQUENTIAL WRITE UP TO (MB/S) 4400
RANDOM READ 4KB UP TO (IOPS) 600,000
RANDOM WRITE 4KB UP TO (IOPS) 600,000
MAXIMUM OPERATING POWER (W) 7.0
IDLE POWER PS3 (MW) 25
LOW POWER L1.2 (MW) 2
OPERATING TEMPERATURES 0??C ??? 70??C
STORAGE TEMPERATURES -40??C ??? 85??C
TERABYTES WRITTEN (TBW) 3300
MEAN TIME BETWEEN FAILURE (MTBF) Up to 1,700,000 Hours
LIMITED WARRANTY 5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
ADVANCED FEATURES TRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
TCG OPAL2.0/Pyrite (Encryption, Data Security)
