TP Link 8 Port Switch with 4 Port PoE


Compare

12 Months Manufacturers Warranty

$85.00

tplink

TP Link 8 Port Switch with 4 Port PoE and steel case

  • Supports PoE power up to 15.4W for each PoE port
  • Supports PoE power up to 53W for all PoE ports
  • Supports PoE IEEE802.3af compliant PDs
  • Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
  • 1K entry MAC address table of the TL-SF1008P with auto-learning and auto-aging
  • LED indicators for monitoring power, link, activity and speed
  • External power adapter supply



Software Specification
Standards and Protocols
 IEEE 802.3, 802.3u, 802.3x, 802.3af
 CSMA/CD, TCP/IP
Basic Function
 Compatible with IEEE 802.3af compliant PDs
 Port Priority Function
 Wire-speed Performance
 MAC Address Auto-Learning and Auto-aging
 IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode
Backbound Bandwidth
 1.6Gbps
MAC Address Table
 1k
Forwarding Rate
 10BASE-T: 14880pps/port
 100BASE-TX: 148800pps/port
Transmission Method
 Store-and-Forward
Hardware Specification
Ports
 8 10/100M Auto-Negotiation RJ45 ports with 4 PoE ports (port-1~port-4), Auto MDI/MDIX
Network Media
 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100?? STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100?? STP (maximum 100m)
LED Indicators
 Power, Link/Act, 100Mbps, PoE Status, PoE MAX
Safety & Emission
 FCC, CE
Dimensions (W*D*H)
 6.7*3.9*1.1 in. (171*98*27 mm)
Environment
 Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Power Supply
 External Power Adapter(Output: 48VDC / 1.25A)
Consumption
 5.8 watts (max. no PD connected)
 58 watts (max. with 53w PD connected
