Gigabyte B660M GAMING DDR4 Intel LGA 1700 mATX Motherboard, 2x DDR4 ~64GB, 1x PCI-E x16, 1x PCI-E x1, 2x M.2, 4x SATA, 1x USB-C, 3x USB 3.2, 2x US
Intel?? B660 GAMING Motherboard with 6+2+1 Phases Hybrid Digital VRM with MOS Heatsink, 2 x PCIe 4.0 M.2, 2.5GbE LAN, Rear USB 3.2 Gen 1 Type-C??, RGB FUSION 2.0, Q-Flash Plus?????????
Supports 12th Gen Intel?? Core??? Series Processors??????
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs??????
6+2+1 Phases Hybrid Digital VRM with MOS Heatsink???
Fast 2.5 GbE GAMING LAN with Bandwidth Management??????
Dual Ultra-Fast NVMe PCIe 4.0 x4 M.2???
Rear SuperSpeed USB 3.2 Gen 1 TYPE-C?? for Fast and Versatile Connections
High Quality Audio Capacitors and Audio Noise Guard???
RGB FUSION 2.0 supports Addressable LED & RGB LED Strips??????
Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP??????
Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card??????
CPU
LGA1700 socket: Support for 12th Generation Intel?? Core???, Pentium?? Gold and Celeron?? Processors*
L3 cache varies with CPU
* Please refer to ‘CPU Support List’ for more information.
Chipset
Intel?? B660 Express Chipset
Memory
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200/3000/2933/2666/2400/2133 MHz memory modules
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer ‘Memory Support List’ for more information.)
Onboard Graphics
Integrated Graphics Processor-Intel?? HD Graphics support:
1 x D-Sub
